Cable tray is very common in our life, but many people don't know much about it. Do you know the height requirement of cable tray? Next, cable tray manufacturers for your detailed introduction, I hope to help you!

一、檢查電纜橋架的高度要求：

1、 Check the height requirements of cable tray:

1、電纜橋架垂直放置時距地面高度不小于1.8m，水平放置時距地面高度不小于2.5m。

1. When the cable tray is placed vertically, the height from the ground shall not be less than 1.8m, and when it is placed horizontally, the height from the ground shall not be less than 2.5m.

2、不符合上述標準時，應加金屬蓋板進行保護。

2. If the above standards are not met, metal cover plate shall be added for protection.

3、特殊電氣室內外的布置。

3. Special electrical indoor and outdoor layout.

4、電纜橋架水平放置時，離地高度小于2.5m，達到2.2m時，可用金屬罩保護。

4. When the cable tray is placed horizontally, the height above the ground is less than 2.5m, and when it reaches 2.2M, it can be protected by metal cover.

5、地下室在梁下2.2米，有的低于2.5米。

5. The basement is 2.2 meters under the beam, and some are less than 2.5 meters.


二、索橋鋪裝標準：

2、 Standard of cable bridge pavement:

1、不要占用人行橫道。

1. Don't occupy the crosswalk.

2、不占用維修區。

2. No maintenance area occupied.

3、干凈漂亮，大方得體。

3. Clean and beautiful, generous and decent.

一般來說，電纜橋架沿墻壁或天花板放置。路面的高度也要參考控制點的位置。不能太高，太高會增加裝修施工難度系數。

In general, cable trays are placed along walls or ceilings. The height of the road should also refer to the position of the control point. Not too high, too high will increase the difficulty coefficient of decoration construction.

三、電纜橋架規格的選用：

3、 Selection of cable tray specifications:

1、電纜橋架高度應按上表選擇，應符合標準電纜填充率，不得超過相關規范的規定值。電力電纜可占40-50%，控制電纜可占50-70%。此外，工藝開發應留有10-25% 的余量。

1. The height of cable tray shall be selected according to the above table, which shall meet the standard cable filling rate and shall not exceed the specified value of relevant specifications. Power cable can account for 40-50%, control cable can account for 50-70%. In addition, 10-25% margin should be reserved for process development.

2、各種彎頭及管件的規格型號要符合標準工程設計標準，并與電纜橋架相匹配。

2. The specifications and models of various elbows and pipe fittings shall meet the standard engineering design standards and match with the cable tray.

3、支架、吊架規格型號的選擇應以橋架規格、層數、跨度等標準配置為依據。并且要滿足裝載要求。

3. The selection of specifications and models of supports and hangers shall be based on the specifications, layers, span and other standard configurations of the bridge. And to meet the loading requirements.

以上是對電纜橋架高度要求的介紹。相信大家看完這篇文章的介紹，都能對電纜橋架有了一定的認識和了解。希望以上內容可以幫到你。另外，如果您想了解更多關于橋架的信息，可以多關注我們網站的動態。

The above is an introduction to the height requirements of cable tray. I believe that after reading this article, you can have a certain understanding of cable tray. I hope the above can help you. In addition, if you want to know more about the bridge, you can pay more attention to the dynamic of our website.
